Product Details
Place of Origin: Hubei, China
Brand Name: Mother Board and Drivers
Certification: CE,CCC,ISO9001,etc
Model Number: GM-170H1-2
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: $799.00--$1,069.00/sets 1-10 Sets
Packaging Details: Professional Wooden Case for Import and Export(with Official Chop)
Delivery Time: 3-7 Working Days
Payment Terms: T/T,Trade Assurance Order on Alibaba(All Payment method Supported on Alibaba Available)
Supply Ability: 500 Sets Per Month
Condition: |
New |
Applicable Industries: |
Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Home Use, Retail, Printing Shops, Construction Works , Other, Advertising Company, All Other Fileds Need Cut Cutting Or Printing |
Weight (KG): |
100 |
Showroom Location: |
Turkey, Viet Nam, Bangladesh, Cambodia |
Video Outgoing-inspection: |
Provided |
Machinery Test Report: |
Provided |
Marketing Type: |
Ordinary Product |
Warranty Of Core Components: |
1 Year |
Core Components: |
Motor |
Warranty: |
1 Year, 1 Year Warranty For Full Machine |
Product Name: |
Digital Cutting Plotter HP45 Ink Box |
Printing Materials: |
White Paper,Kraft, Etc |
Cutting Size: |
1650mm To 2050mm |
Paper Size: |
1700mm To 2100mm |
Printing Tool: |
Universal HP45 Ink Box Or Cartridge |
Ink Cartridge Type: |
HP45 Ink Box Or Cartridge 2 To 4 Printing Heads Available |
Printing Resolution: |
150-600DPI, Optional And Settable On Menu |
Power Supply Voltage: |
220V/50Hz, 110V, 60HZ Optional |
CAD File Format: |
HP-GL, PLT, DXF, Etc |
Condition: |
New |
Applicable Industries: |
Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Home Use, Retail, Printing Shops, Construction Works , Other, Advertising Company, All Other Fileds Need Cut Cutting Or Printing |
Weight (KG): |
100 |
Showroom Location: |
Turkey, Viet Nam, Bangladesh, Cambodia |
Video Outgoing-inspection: |
Provided |
Machinery Test Report: |
Provided |
Marketing Type: |
Ordinary Product |
Warranty Of Core Components: |
1 Year |
Core Components: |
Motor |
Warranty: |
1 Year, 1 Year Warranty For Full Machine |
Product Name: |
Digital Cutting Plotter HP45 Ink Box |
Printing Materials: |
White Paper,Kraft, Etc |
Cutting Size: |
1650mm To 2050mm |
Paper Size: |
1700mm To 2100mm |
Printing Tool: |
Universal HP45 Ink Box Or Cartridge |
Ink Cartridge Type: |
HP45 Ink Box Or Cartridge 2 To 4 Printing Heads Available |
Printing Resolution: |
150-600DPI, Optional And Settable On Menu |
Power Supply Voltage: |
220V/50Hz, 110V, 60HZ Optional |
CAD File Format: |
HP-GL, PLT, DXF, Etc |
| Main Features | |||
| 1.High-speed Servo Control, Full Closed-loop Positioning (to Ensure Accurate Output of Various Unexpected Situations) | |||
| 2.Independent Output Manager Supports File Background Automatic Queuing Printing | |||
| 3.Using advanced SOPC technology | |||
| 4.Support breakpoint resume, ensure reliable data transmission and printing | |||
| 5.Automatic printing online | |||
| 6.Two Printing Heads/Three Printing Heads/Four Printing Heads Optional | |||
| Technical Parameters | |||
| Type | Dual Heads | Three Heads | Four Heads |
| Product Model | 165-2/185-2/205-2 | 160-3/180-3/200-3 | 155-4/175-4/195-4 |
| Printing Width(cm) | 165/185/205 | 160/180/200 | 155/175/195 |
| Feeding Paper Width(cm) | 170/190/210 | 170/190/210 | 170/190/210 |
| Printing Speed | Two-way High Speed 93 ㎡/h; Two-way High speed 131 ㎡/h;Two-way High Speed 163 ㎡/h | ||
| Printing format | HPGL Drawing Language, Compatible with Domestic and Foreign CAD Software, Special format can be Customized | ||
| Print resolution | 150-600DPI | ||
| Type of Nozzle | HP45A, C51645A | ||
| Line quality | Clear, Smooth, No Seam, Optional 1-8 Lines | ||
| Nozzle Cleaning | Automatic Cleaning Before Printing | ||
| Paper Loading | Front Heightening Device to Support Paper Roll with Diameter of 28cm | ||
| Paper Feeding | Hidden Infrared Precise Paper Feeding System, Continuous 700 Meters without Deviation | ||
| Receiving and Delivering Paper | Unattended Automatic Paper Receiving and Feeding | ||
| Print Media | 40-80g, Ordinary Roll Printing Paper;80-250g, Single Brown Paper | ||
| Communication Interface | Network Port, Multiple Computers can Separately Control Printing | ||
| Power Supply Voltage | 220V/50Hz, 110V, 60Hz Power Optional | ||
| Button Panel | Press the Keys Operation,Simple, Convenient, Durable | ||
| Machine Structure | Die Standardized Metal Structure, High Precision and Long Life | ||
| Output Center | 1.Support Manual or Automatic Printing 2.Optional Ink-saving Mode 3.Support Online Printing | ||
